Edge of North Polar Erg

This scene is from early spring in the northern hemisphere of Mars. These dunes are covered with a layer of seasonal carbon dioxide ice (dry ice). Bluish cracks in the ice are visible across the top of some of the dunes.

Dark fan-shaped deposits around the edges of the dunes are at spots where the ice has sublimated (gone directly from ice to gas) and the ice layer has ruptured, allowing the sand from the dune to escape out from under the ice. The sand is then free to be blown by the wind.

This image is one product from an observation by the High Resolution Imaging Science Experiment (HiRISE) camera taken on Sept. 30, 2011, at 73.3 degrees north latitude, 355.1 degrees east longitude. Other image products from the same observation are at http://www.uahirise.org/ESP_024265_2535 .

HiRISE is one of six instruments on NASA's Mars Reconnaissance Orbiter. The University of Arizona, Tucson, operates the orbiter's HiRISE camera, which was built by Ball Aerospace & Technologies Corp., Boulder, Colo. NASA's Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the Mars Exploration Rover and Mars Reconnaissance Orbiter projects for the NASA Science Mission Directorate, Washington.
