Gores in the Strands

Saturn's F ring
November 29, 2007
PIA NumberPIA09782
Language
  • english

Seen here is the end result of the process that occurs every time the moon Prometheus closely approaches Saturn's F ring. The moon cuts a dark channel in the ring's inner edge that then shears out over successive orbits, giving the ring the unique appearance seen here.

Of particular interest in this view is the faint fan of small-scale gores seen at the ring's ansa. These features are left of center in the frame, immediately to the left of a bright clump there. The small gores are formed in the same manner as the larger ones created by Prometheus: a small moonlet orbiting in the F ring forms gores because of its eccentric orbit relative to the overall F ring.

This process is described in detail, along with a movie of Prometheus creating one of the streamer/channel features, in Soft Collision.

The view is toward the sunlit side of the rings from about 3 degrees below the ringplane.The image was taken in visible light with the Cassini spacecraft narrow-angle camera on Oct. 25, 2007. The view was acquired at a distance of approximately 624,000 kilometers (388,000 miles) from Saturn and at a Sun-ring-spacecraft, or phase, angle of 23 degrees. Image scale is 3 kilometers (2 miles) per pixel.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging operations center is based at the Space Science Institute in Boulder, Colo.

For more information about the Cassini-Huygens mission visit http://saturn.jpl.nasa.gov . The Cassini imaging team homepage is at http://ciclops.org .

Credit: NASA/JPL/Space Science Institute
