Musical Rings

Nearly the entire ring system can be seen in this view. The diaphanous C ring appears at the upper right, followed by the multi-hued B ring. Next, the famous Cassini division (4,800 kilometers, or 2,980 miles wide) separates the A and B rings. The outer edge of the B ring which forms the inner boundary of the Cassini division is maintained by a gravitational resonance with Mimas. Near the outer edge of the A ring are the Encke Gap (325 kilometers, or 202 miles wide) and the barely visible Keeler Gap (35 kilometers, or 22 miles wide). The faint, thread-like F ring is discernible just beyond the main rings.

The image was obtained with the Cassini spacecraft narrow angle camera on August 27, 2004, at a distance of 9.1 million kilometers (5.6 million miles) from Saturn. Images taken with red, green and blue filters were combined to create this color view. The moons have been enhanced in brightness to increase their visibility. The image scale is 54 kilometers (34 miles) per pixel.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the Cassini-Huygens mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging team is based at the Space Science Institute, Boulder, Colo.

For more information about the Cassini-Huygens mission, visit http://saturn.jpl.nasa.gov and the Cassini imaging team home page, http://ciclops.org .

Image Credit:

NASA/JPL/Space Science Institute
