Propeller Motion

A mmagnified view of the general orientation of the
March 29, 2006
PIA NumberPIA07791
Language
  • english

This magnified view illustrates the general orientation of the "propeller" features in Saturn's rings as they orbit the planet. The propellers are features detected in Cassini images that reveal the gravitational influence of moonlets approximately 100 meters (300 feet) in diameter.

The view is from one of the two Saturn orbit insertion images, taken on July 1, 2004, in which the propellers were discovered.

The two dashes of the propeller are oriented in the direction of orbital motion. The "leading" dash is also slightly closer to Saturn; this "radial offset" is about 300 meters (1000 feet). The unseen moonlet lies in the center of the structure.

The grainy appearance of the image is due to magnification and the fact that the propellers are very faint--just visible above the level of background noise. Consequently, the image enhancement procedures used have also enhanced the noise.

This propeller image is identified as "feature 1" in Four Propellers. The original Cassini spacecraft narrow-angle camera image has been magnified from its original scale for presentation.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging operations center is based at the Space Science Institute in Boulder, Colo.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging operations center is based at the Space Science Institute in Boulder, Colo.
For more information about the Cassini-Huygens mission visit http://saturn.jpl.nasa.gov . The Cassini imaging team homepage is at http://ciclops.org .

Credit: NASA/JPL/Space Science Institute
