Sunrise on Mars (Viking 2)

The small dot of the Sun peeks over a dark Martian horizon.
The Sun rises over Mars' Utopia Planitia in this Viking 2 image.
May 1, 2019
Historical DateJune 14, 1978
PIA NumberPIA00576
  • english

Original Caption

A Martian sunrise was captured in this Viking 2 Lander picture taken June 14, 1978, at the spacecraft's Utopia Planitia landing site.

The data composing this image were acquired just as the Sun peaked over the horizon on the Lander's 631st sol (Martian solar day). Pictures taken at dawn (or dusk) are quite dark except where the sky is brightened above the Sun's position.

The glow in the sky results as light from the Sun is scattered and preferentially absorbed by tiny particles of dust and ice in the atmosphere.

When the Viking cameras are calibrated for darker scenes, the "sky glow" tends to saturate their sensitivity and produce the bright regions seen here. The "banding" and color separation effects are also artifacts, rather than real features, and are introduced because the cameras are not able to record continuous gradations of light. The cameras must represent such gradations in steps (bands) of brightness and color, and the process sometimes produces some "false" colors within the bands.

The scattering of light closest to the Sun's position tends to enhance blue wavelengths. The narrowing sky glow nearer the horizon above the Sun's position occurs as a result of light extinction. At that elevation, the optical path of sunlight through the atmosphere is at its longest penetration angle, and a substantial portion of the light is simply prevented from reaching the cameras by the dust, ice particles and other material in its way.
