6 min read

NASA’s PACE To Investigate Oceans, Atmosphere in Changing Climate

Earth is complex – the atmosphere, ocean, land, and each small interwoven facet of those systems is a puzzle piece that connects and fills out the full picture. With a changing climate, the puzzle is becoming more complex – and important – to understand.
Credits: NASA / Ryan Fitzgibbons and Emme Watkins

Earth’s oceans and atmosphere are changing as the planet warms. Some ocean waters become greener as more microscopic organisms bloom. In the atmosphere, dust storms born on one continent affect the air quality of another, while smoke from massive wildfires can blanket entire regions for days.

NASA’s newest Earth-observing satellite, called PACE (Plankton, Aerosol, Cloud, ocean Ecosystem), is launching in February 2024 to help us better understand the complex systems driving these and other global changes that come with a warming climate.

PACE will help assess ocean health by measuring the distribution of phytoplankton – tiny plant-like organisms and algae that sustain the marine food web. It will also extend records of key atmospheric variables associated with air quality and Earth's climate. Credit: NASA’s Scientific Visualization Studio

“The ocean and atmosphere interact in ways that need ongoing research to fully understand,” said Jeremy Werdell, project scientist for the PACE mission at NASA’s Goddard Space Flight Center in Greenbelt, Maryland.With PACE, we’ll open our eyes to many new aspects of climate change.”

The ocean is changing color

Climate change’s impact on the ocean are numerous, from sea level rise to marine heat waves to a loss of biodiversity. With PACE, researchers will be able to study its effect on marine life in its smallest form.

Phytoplankton are microscopic, plant-like organisms that float near the water’s surface and form the center of the aquatic food web, providing food to all sorts of animals ranging from shellfish to finfish to whales. There are thousands of species of phytoplankton, each with different niches in the ocean.

An aerial view of a portion of the planet shows white, wispy cloud coverage over both land and ocean. Clouds are seen in the bottom left corner extending up towards the top left corner but dwindling as it rises. Clouds are also seen in the top right corner. A green colored land mass is seen along the bottom third of the image. There are some islands off the coast of the land as well. In the dark blue ocean, are vibrant swirls of teal and green phytoplankton blooms.
During the spring and summer in the Barents Sea, north of Norway and Russia, blue and green blooms of phytoplankton are often visible. The Moderate Resolution Imaging Spectroradiometer (MODIS) aboard NASA’s Aqua satellite captured this true-color image on July 15, 2021.
Credit: NASA Earth Observatory
NASA Earth Observatory

While a single phytoplankton typically can’t be seen with the naked eye, communities of trillions of phytoplankton, called blooms, can be seen from space. Blooms often take on a greenish tinge due to the chlorophyll molecules that phytoplankton, like land-based plants, use to make energy through photosynthesis.

According to Ivona Cetinić, an oceanographer in the Ocean Ecology Lab at NASA Goddard, phytoplankton are responding to changes in their environment. Differences in ocean temperatures, nutrients, or sunlight availability can cause a species to boom or bust.

From space, those changes in phytoplankton populations manifest as differences in hue, allowing scientists to study phytoplankton abundance and diversity from afar, and at a global scale. And scientists recently found that the ocean is turning a touch greener.

In a study published in 2023, researchers used chlorophyll concentration data collected for more than 20 years by the Moderate Resolution Imaging Spectroradiometer (MODIS) on NASA’s Aqua satellite to determine not only when and where phytoplankton blooms occurred, but also how healthy and abundant they were.

The image consists of a virtual representation of the earth, a flattened map of the globe with Africa taking up the left-most point and the Americas on the right. All land is in a gray shade while the ocean is white. In parts of the ocean, primarily around the equator and spreading north and south from there, are blots of various shades of green. A bar below the map shows what the shades of green represent – change in ocean color. The lightest green is less change while the darker green shades represent a greater change in ocean color.
After analyzing ocean color data from the MODIS instrument on NASA’s Aqua satellite, scientists found that portions of the ocean had greened up with more chlorophyll-carrying phytoplankton.
Credit: NASA Earth Observatory
NASA Earth Observatory

PACE’s Ocean Color Instrument (OCI), a hyperspectral sensor, will take marine science a leap further by allowing researchers to remotely differentiate phytoplankton by type. (Historically, species could only be determined by direct sampling of the water.) Each community has its own color signature that an instrument like OCI can identify.

Identification of phytoplankton types is key because different phytoplankton play vastly different roles in aquatic ecosystems. They have beneficial roles, like fueling the food chain or drawing down carbon dioxide from the atmosphere for photosynthesis. Some phytoplankton populations sequester carbon as they die and sink to the deep ocean; others release the gas back into the atmosphere as they decay near the surface.

But some, like those in harmful algae blooms, can negatively impact humans and aquatic ecosystems. And the presence of harmful algae can also tell us something about the quality of the water sources, such as the presence of too many nutrients from human activities. By identifying these communities in the ocean, scientists can tease out information about how and where phytoplankton are affected by climate change, and how changes in these tiny organisms may affect other creatures and ocean ecosystems.

Particles in the air feed phytoplankton at sea

Beyond their role as the grass of the sea, phytoplankton also play a role in a complex dance between atmosphere and ocean. And PACE will see both partners in this dance.

From space, with a view of the whole planet every two days, PACE will track both microscopic organisms in the ocean and microscopic particles in the atmosphere called aerosols. How these two interact will provide scientists with additional insights into the impact of a changing climate.

This model shows the movement of aerosols over land and water in Aug. 2017. Hurricanes and tropical storms stand out due to the large amounts of sea salt particles caught up in their swirling winds. Dust blowing out of the Sahara can get caught by water droplets and rained out of the atmosphere. Smoke from massive wildfires in the Pacific Northwest of North America are carried across the Atlantic to Europe. Credit: NASA’s Scientific Visualization Studio

For example, when aerosol particles from the atmosphere are deposited onto the ocean, they can provide essential nutrients to spark phytoplankton blooms. Winds sometimes carry ash and dust from wildfires and dust storms over the ocean. When these particles fall into the water, they can act as a fertilizer, providing nutrients such as iron that allow phytoplankton populations to grow.

As we go forward in a warming climate, with a potential for more forest fires and, therefore, a greater amount of ash deposition, we can assume there are going to be changes in the phytoplankton communities,

Ivona Cetinić

Ivona Cetinić

Oceanographer - Ocean Ecology Lab at NASA Goddard

This visualization shows an example of a wildfire transitioning from day to night in the Sierra Nevada mountains. Credit: NASA’s Scientific Visualization Studio

While PACE’s color-detecting instrument will see changes in phytoplankton, the satellite also carries two instruments called polarimeters – SPEXone and HARP2 – that use properties of light (polarization) to observe aerosol particles and clouds. Scientists will be able to measure the size, composition, and abundance of these microscopic particles in our atmosphere.

Smoke, pollutants and dust seed the clouds, too

New data from PACE characterizing atmospheric particles will enable scientists to examine one of the trickiest components of climate change to model: how clouds and aerosols interact.

Clouds form when water condenses on airborne particles such as smoke and ash. One easy to spot example is ship tracks, which occur when water vapor condenses and forms bright, low-lying clouds on pollutants emitted by ships.

The image is an aerial view overlooking the ocean and clouds. The background of the image is the deep blue of the ocean while the foreground shows white wispy clouds. The clouds cover most of the image, so blue is only peeking through in some spots. The clouds near the borders of the image are thin but cover a lot of area. Near the center of the image are clouds tracing streaks through the sky. The streaked clouds – ship tracks – primarily run diagonally in the direction of bottom right up to top left.
Ship tracks above the northern Pacific Ocean. NASA image captured July 3, 2010, by the Aqua satellite.
Credit: NASA

Different types of aerosols also influence the characteristics of clouds, such as their brightness, which is driven by cloud droplet size and number. These traits can lead to different impacts – either warming or cooling – on Earth’s surface.

For instance, a bright cloud or plume of aerosol particles hovering low over a much darker ocean reflects more light back into space, causing a localized cooling effect. Other times, both clouds and aerosols have a warming effect called blanketing. Thin plumes high up in the atmosphere absorb heat from Earth's surface and then radiate it back toward the ground.

“From a climate perspective, the relationship between aerosols and clouds is one of the largest sources of uncertainty in our understanding of the climate,” said Kirk Knobelspiesse, polarimetry lead for the PACE mission at NASA Goddard. The satellite's new insights into aerosol particles will help scientists fill in knowledge gaps and deepen our understanding of that relationship.
