Jupiter and Io

This is a montage of New Horizons images of Jupiter and its volcanic moon Io, taken during the spacecraft’s Jupiter flyby in early 2007.

The Jupiter image is an infrared color composite taken by the spacecraft’s near-infrared imaging spectrometer, the Linear Etalon Imaging Spectral Array (LEISA) at 1:40 UT on Feb. 28, 2007. The infrared wavelengths used (red: 1.59 µm, green: 1.94 µm, blue: 1.85 µm) highlight variations in the altitude of the Jovian cloud tops, with blue denoting high-altitude clouds and hazes, and red indicating deeper clouds. The prominent bluish-white oval is the Great Red Spot. The observation was made at a solar phase angle of 75 degrees but has been projected onto a crescent to remove distortion caused by Jupiter’s rotation during the scan.

The Io image, taken at 00:25 UT on March 1st 2007, is an approximately true-color composite taken by the panchromatic Long-Range Reconnaissance Imager (LORRI), with color information provided by the 0.5 µm (“blue”) and 0.9 µm (“methane”) channels of the Multispectral Visible Imaging Camera (MVIC). The image shows a major eruption in progress on Io’s night side, at the northern volcano Tvashtar. Incandescent lava glows red beneath a 330-kilometer high volcanic plume, whose uppermost portions are illuminated by sunlight. The plume appears blue due to scattering of light by small particles in the plume.

This montage appears on the cover of the Oct. 12, 2007 issue of Science magazine.

New Horizons passed Jupiter on Feb. 28, 2007, riding the planet’s gravity to boost its speed and shave three years off its trip to Pluto.

It was the eighth spacecraft to visit Jupiter – but a combination of trajectory, timing and technology allowed it to explore details no probe had seen before, such as lightning near the planet’s poles, the life cycle of fresh ammonia clouds, boulder-size clumps speeding through the planet’s faint rings, the structure inside volcanic eruptions on its moon Io, and the path of charged particles traversing the previously unexplored length of the planet’s long magnetic tail.

“The Jupiter encounter was successful beyond our wildest dreams,” says New Horizons Principal Investigator Alan Stern. “it was a chance for us to take sophisticated instruments to places in the Jovian system where other spacecraft couldn’t go, and to return important data that adds tremendously to our understanding of the solar system’s largest planet and its moons, rings and atmosphere.”

From January through June, New Horizons’ seven science instruments made more than 700 separate observations of the Jovian system – twice the activity planned at Pluto – with most of them coming in the eight days around closest approach to Jupiter.

Jovian weather was high on the list, as New Horizons’ visible light, infrared and ultraviolet remote-sensing instruments probed Jupiter’s atmosphere for data on cloud structure and composition. They saw clouds form from ammonia welling up from the lower atmosphere and heat-induced lighting strikes in the polar regions – the first polar lighting ever observed beyond Earth, demonstrating that heat moves through water clouds at virtually all latitudes across Jupiter. They made the most detailed size and speed measurements yet of “waves” that run the width of planet and indicate violent storm activity below. Additionally, New Horizons snapped the first close-up images of the Little Red Spot, a nascent storm about half the size of Jupiter’s larger Great Red Spot and about 70 percent of Earth’s diameter, gathering new information on storm dynamics.

Under a range of lighting and viewing angles, New Horizons also captured the clearest images ever of the tenuous Jovian ring system. In them, scientists spotted clumps of debris that may indicate a recent impact inside the rings, or some more exotic phenomenon; movies made from New Horizons images also offer an unprecedented look at ring dynamics, with the tiny inner moons Metis and Adrastea shepherding the materials around the rings. A search for smaller moons inside the rings – and possible new sources of the dusty material – found no bodies wider than a kilometer.

The mission’s investigations of Jupiter’s four largest moons focused on Io, the closest to Jupiter and whose active volcanoes blast tons of material into the Jovian magnetosphere (and beyond). New Horizons spied 11 different volcanic plumes of varying size, three of which were seen for the first time and one – a spectacular 200-mile-high eruption rising above the volcano Tvashtar – that offered an unprecedented opportunity to trace the structure and motion of the plume as it condensed at high altitude and fell back to the moon’s surface. In addition, New Horizons spotted the infrared glow from at least 36 Io volcanoes, and measured lava temperatures up to 1,900 degrees Fahrenheit, similar to many terrestrial volcanoes.

New Horizons’ global map of Io’s surface backs the moon’s status as the solar system’s most active body, showing more than 20 geological changes since the Galileo Jupiter orbiter provided the last close-up look in 2001. The remote imagers also kept watch on Io in the darkness of Jupiter’s shadow, noting mysterious glowing gas clouds above dozens of volcanoes. Scientists suspect that this gas helps to resupply Io’s atmosphere.

New Horizons' flight down Jupiter's magnetotail gave it an unprecedented look at the vast region dominated by the planet's strong magnetic field. Looking specifically at the fluxes of charged particles that flow hundreds of millions of miles beyond the giant planet, the New Horizons particle detectors saw evidence that tons of material from Io’s volcanoes move down the tail in large, dense, slow-moving blobs. By analyzing the observed variations in particle fluxes over a wide range of energies and scales, New Horizons scientists are exploring how the volcanic gases from Io are ionized, trapped and energized by Jupiter's magnetic field, then ultimately ejected from the system.
