Scenic Shock

Saturn's northern storm marches through the planet's atmosphere in the top right of this false-color mosaic from NASA's Cassini spacecraft.

See Chronicling Saturn’s Northern Storm to learn more about this storm and watch its development over several months. Earlier in the Cassini mission, the spacecraft chronicled a smaller storm in the southern hemisphere, called the "Dragon Storm." See The Dragon Storm to learn more about that storm and to see a similar, false-color view.

Saturn's atmosphere and its rings are shown here in a false-color composite made from 12 images taken in near-infrared light through filters that are sensitive to varying degrees of methane absorption. Red and orange colors in this view indicate clouds that are deep in the atmosphere. Yellow and green colors, most noticeable along the top edge of the view, indicate intermediate clouds. White and blue indicate high clouds and haze. The rings appear as a thin horizontal line of bright blue because they are outside of the atmosphere and not affected by methane absorption.

This view looks toward the northern, sunlit side of the rings from just above the ring plane.

The images were taken with the Cassini spacecraft wide-angle camera using a combination of spectral filters sensitive to wavelengths of near-infrared light. The images filtered at 890 nanometers are projected as blue. The images filtered at 728 nanometers are projected as green, and images filtered at 752 nanometers are projected as red.

The images were taken on Jan. 11, 2011, over about 50 minutes, at a distance of approximately 569,000 miles (915,000 kilometers) from Saturn and at a sun-Saturn-spacecraft, or phase, angle of 45 degrees. The images were re-projected to the same viewing geometry, so that scale in this final mosaic is 63 miles (102 kilometers) per pixel.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate in Washington. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging team is based at the Space Science Institute, Boulder, Colo.

For more information about the Cassini-Huygens mission visit http://saturn.jpl.nasa.gov or http://www.nasa.gov/cassini . The Cassini imaging team homepage is at http://ciclops.org .

Credit: NASA/JPL-Caltech/Space Science Institute
