Wave Maker

The Cassini spacecraft catches Saturn's moon Daphnis making waves and casting shadows from the narrow Keeler Gap of the planet's A ring in this view taken around the time of Saturn's August 2009 equinox.

Daphnis (8 kilometers, or 5 miles across) is almost invisible in this view, but the shadows cast on the wide A ring can be seen below the center of the image. The Enke Gap of the A ring, which is wider than the Keeler Gap, is on the right. Saturn's thin F ring is on the left of the view. See Slanting Shadows for a similar, closer view.

More than a dozen background stars are visible in this image.

Daphnis has an inclined orbit and its gravitational pull perturbs the orbits of the particles of the A ring forming the Keeler Gap's edge and sculpts the edge into waves having both horizontal (radial) and out-of-plane components. Material on the inner edge of the gap orbits faster than the moon so that the waves there lead the moon in its orbit. Material on the outer edge moves slower than the moon, so waves there trail the moon. See Wavy Shadows to learn more about this process.

The novel illumination geometry that accompanies equinox lowers the sun's angle to the ringplane, significantly darkens the rings, and causes out-of-plane structures to look anomalously bright and cast shadows across the rings. These scenes are possible only during the few months before and after Saturn's equinox which occurs only once in about 15 Earth years. Before and after equinox, Cassini's cameras have spotted not only the predictable shadows of some of Saturn's moons (see Across Resplendent Rings), but also the shadows of newly revealed vertical structures in the rings themselves (see A Small Find Near Equinox).

This view looks toward the northern, sunlit side of the rings from about 13 degrees above the ringplane.

The image was taken in visible light with the Cassini spacecraft narrow-angle camera on Aug. 16, 2009. The view was acquired at a distance of approximately 2.1 million kilometers (1.3 million miles) from Saturn and at a Sun-Saturn-spacecraft, or phase, angle of 108 degrees. Image scale is 12 kilometers (8 miles) per pixel.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging operations center is based at the Space Science Institute in Boulder, Colo.

For more information about the Cassini-Huygens mission visit http://saturn.jpl.nasa.gov . The Cassini imaging team homepage is at http://ciclops.org .

Credit: NASA/JPL-Caltech/Space Science Institute
