Adding Composition Data About Mars Gullies

The highly incised Martian gullies seen in the image resemble gullies on Earth that are carved by liquid water. However, when the gullies are observed with the addition of mineralogical information, no evidence for alteration by water appears.

The pictured area spans about 2 miles (3 kilometers) on the eastern rim of Hale Crater. The High Resolution Imaging Science Experiment (HiRISE) camera on NASA's Mars Reconnaissance Orbiter took the visible-light image. Color-coded compositional information comes from the same orbiter's Compact Reconnaissance Imaging Spectrometer for Mars (CRISM).

Color coding in light blue corresponds to surface composition of unaltered mafic material, of volcanic origin. Mafic material from the crater rim is carved and transported downslope along the gully channels. No hydrated minerals are observed within the gullies, in the data from CRISM, indicating limited interaction or no interaction of the mafic material with liquid water. These findings and related observations at about 100 other gully sites on Mars suggest that a mechanism not requiring liquid water may be responsible for carving these gullies on Mars. (Gullies on Mars are a different type of feature than seasonal dark streaks called recurring slope lineae or RSL; water in the form of hydrated salt has been identified at RSL sites.)

The HiRISE image is a portion of HiRISE observation PSP_002932_1445. The other image is from the same HiRISE observation, with a CRISM mineral map overlaid.

Building and operating CRISM has been led by Johns Hopkins University Applied Physics Laboratory, Laurel, Maryland. The University of Arizona, Tucson, operates HiRISE, which was built by Ball Aerospace & Technologies Corp., Boulder, Colo. NASA's Jet Propulsion Laboratory, a division of the Caltech in Pasadena, California, manages the Mars Reconnaissance Orbiter Project for NASA's Science Mission Directorate, Washington. Lockheed Martin Space Systems, Denver, built the orbiter.
