Quieted Storm

The Cassini spacecraft examines Saturn and the planet's northern hemisphere, which was ravaged by a huge storm for much of 2011.

See Chronicling Saturn's Northern Storm and Encircling a Giant to learn more about the storm.

Four of Saturn's moons join the planet here. Two of these -- Janus and Epimetheus -- are almost lost in this view due to their small size. Mimas (246 miles, or 396 kilometers across) appears as a bright dot below the rings just to the right of the center of the image. Enceladus (313 miles, or 504 kilometers across) is visible below the rings on the far right of the image. Janus (111 miles, or 179 kilometers across) can just barely be discerned as a tiny speck past Enceladus on the right edge of the image. Epimetheus (70 miles, or 113 kilometers across) is likewise tiny, and can be detected on the extreme left of the image above the rings.

This view looks toward the southern, unilluminated side of the rings from just below the ringplane.

Relative to Saturn and other objects in this view, Janus and Epimetheus have been brightened by a factor 1.5 and 1.4 respectively.
The image was taken with the Cassini spacecraft wide-angle camera on Feb. 11, 2012 using a spectral filter sensitive to wavelengths of near-infrared light centered at 752 nanometers. The view was acquired at a distance of approximately 1.7 million miles (2.8 million kilometers) from Saturn and at a Sun-Saturn-spacecraft, or phase, angle of 60 degrees. Image scale on Saturn is 105 miles (170 kilometers) per pixel.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging operations center is based at the Space Science Institute in Boulder, Colo.

For more information about the Cassini-Huygens mission visit http://saturn.jpl.nasa.gov . The Cassini imaging team homepage is at http://ciclops.org .

Credit: NASA/JPL-Caltech/Space Science Institute
