Stubby Shadow

Saturn's small moon Pan, brightly overexposed, casts a short shadow on the A ring in this image taken before the planet's August 2009 equinox.

Pan (28 kilometers, or 17 miles across) orbits in the Encke Gap of the A ring and can be seen near the center of the image. The novel illumination geometry that accompanies equinox lowers the sun's angle to the ringplane, significantly darkens the rings, and causes out-of-plane structures to look anomalously bright and cast shadows across the rings. These scenes are possible only during the few months before and after Saturn's equinox, which occurs only once in about 15 Earth years. Before and after equinox, Cassini's cameras have spotted not only the predictable shadows of some of Saturn's moons (see Across Resplendent Rings), but also the shadows of newly revealed vertical structures in the rings themselves (see A Small Find Near Equinox).

This view looks toward the southern, sunlit side of the rings from about 58 degrees below the ringplane.

The image was taken in visible light with the Cassini spacecraft narrow-angle camera on May 9, 2009. The view was acquired at a distance of approximately 908,000 kilometers (564,000 miles) from Pan. Image scale is 5 kilometers (3 miles) per pixel.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging operations center is based at the Space Science Institute in Boulder, Colo.

For more information about the Cassini-Huygens mission visit http://saturn.jpl.nasa.gov . The Cassini imaging team homepage is at http://ciclops.org .

Credit: NASA/JPL/Space Science Institute
