Western Arcadia Planitia

This is a Mars Odyssey visible color image of an unnamed crater in western Arcadia Planitia (near 39 degrees N, 179 degrees E). The crater shows a number of interesting internal and external features that suggest that it has undergone substantial modification since it formed. These features include concentric layers and radial streaks of brighter, redder materials inside the crater, and a heavily degraded rim and ejecta blanket. The patterns inside the crater suggest that material has flowed or slumped towards the center. Other craters with features like this have been seen at both northern and southern mid latitudes The distribution of these kinds of craters suggests the possible influence of surface or subsurface ice in the formation of these enigmatic features. The image was taken on September 29, 2002 during late northern spring. This is an approximate true color image, generated from a long strip of visible red (654 nm), green (540 nm), and blue (425 nm) filter images that were calibrated using a combination of pre-flight measurements and Hubble images of Mars. The colors appear perhaps a bit darker than one might expect; this is most likely because the images were acquired in late afternoon (roughly 4:40 p.m. local solar time) and the low Sun angle results in an overall darker surface.
