Carina Nebula Jets (NIRCam Narrowband Filters Compass Image)

Image titled James Webb Space Telescope, Carina Nebula, NGC 3324 with compass arrows, scale bar, and color key. Image shows bright eight-pointed stars scattered across a dense orange-brown undulating cloudscape below a deep blue starscape. At the bottom left are compass arrows indicating the orientation of the image on the sky. The north arrow points in the 4 o’clock direction. The east arrow points toward 1 o’clock. At the lower right is a scale bar labeled 2 light-years. The length of the scale bar is a little less than one-eighth the total width of the image. Below the image is a color key showing which NIRCam filters were used to create the image and which visible-light color is assigned to each filter. From left to right, NIRCam filters are: F187N is blue; F444W is green; and F470N is red.

Image of the Cosmic Cliffs, a region at the edge of a gigantic, gaseous cavity within NGC 3324, captured by Webb’s Near-Infrared Camera (NIRCam), with compass arrows, scale bar, and color key for reference.

The north and east compass arrows show the orientation of the image on the sky. Note that the relationship between north and east on the sky (as seen from below) is flipped relative to direction arrows on a map of the ground (as seen from above).

The scale bar is labeled in light-years, which is the distance that light travels in one Earth-year. It takes 2 years for light to travel a distance equal to the length of the bar. One light-year is equal to about 5.88 trillion miles or 9.46 trillion kilometers.

This image shows invisible near-infrared wavelengths of light that have been translated into visible-light colors. The color key shows which NIRCam filters that were used when collecting the light. The color of each filter name is the visible light color used to represent the infrared light that passes through that filter.

Webb’s NIRCam was built by a team at the University of Arizona and Lockheed Martin’s Advanced Technology Center.

Read the full image caption.

About the Object

  • R.A. Position
    R.A. PositionRight ascension – analogous to longitude – is one component of an object's position.
    10:36:59.0
  • Dec. Position
    Dec. PositionDeclination – analogous to latitude – is one component of an object's position.
    -58:37:00.0
  • Constellation
    ConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.
    Carina
  • Distance
    DistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.
    7,600 light-years (2,300 parsecs)
  • Dimensions
    DimensionsThe physical size of the object or the apparent angle it subtends on the sky.
    Image is about 7.3 arcminutes across (16 light-years)

About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.

    This image was created with Webb data from proposal 2731 . It is part of Webb Early Release Observations.

    The Early Release Observations and associated materials were developed, executed, and compiled by the ERO production team:

    Jaclyn Barrientes, Claire Blome, Hannah Braun, Matthew Brown, Margaret Carruthers, Dan Coe, Joseph DePasquale, Nestor Espinoza, Macarena Garcia Marin, Karl Gordon, Alaina Henry, Leah Hustak, Andi James, Ann Jenkins, Anton Koekemoer, Stephanie LaMassa, David Law, Alexandra Lockwood, Amaya Moro-Martin, Susan Mullally, Alyssa Pagan, Dani Player, Klaus Pontoppidan, Charles Proffitt, Christine Pulliam, Leah Ramsay, Swara Ravindranath, Neill Reid, Massimo Robberto, Elena Sabbi, Leonardo Ubeda.

    The EROs were also made possible by the foundational efforts and support from the JWST instruments, STScI planning and scheduling, Data Management teams, and Office of Public Outreach.

  • Instrument
    InstrumentThe science instrument used to produce the data.
    NIRCam
  • Exposure Dates
    Exposure DatesThe date(s) that the telescope made its observations and the total exposure time.
    3 June 2022
  • Filters
    FiltersThe camera filters that were used in the science observations.
    F187N, F444W, F470N
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    NGC 3324, Carina Nebula
  • Object Description
    Object DescriptionThe type of astronomical object.
    Star-forming region in the Carina Nebula
  • Release Date
    December 15, 2022
  • Science Release
    NASA’s Webb Unveils Young Stars in Early Stages of Formation
    Read the release
  • Credit
    Megan Reiter (Rice University); Image: NASA, ESA, CSA, STScI; Image Processing: Joseph DePasquale (STScI), Anton Koekemoer (STScI)

Downloads

  • Annotated, Full Res (For Display), 14564 × 11227
    png (158.15 MB)
  • Annotated, Full Res (For Print), 14564 × 11227
    tif (174.1 MB)
  • Annotated, 2000 × 1542
    png (2.91 MB)
  • Unannotated, Full Res (For Display), 14570 × 8452
    png (154.42 MB)
  • Unannotated, Full Res (For Print), 14570 × 8452
    tif (189.26 MB)
  • Unannotated, 2000 × 1160
    png (2.88 MB)
Image titled James Webb Space Telescope, Carina Nebula, NGC 3324 with compass arrows, scale bar, and color key. Image shows bright eight-pointed stars scattered across a dense orange-brown undulating cloudscape below a deep blue starscape. At the bottom left are compass arrows indicating the orientation of the image on the sky. The north arrow points in the 4 o’clock direction. The east arrow points toward 1 o’clock. At the lower right is a scale bar labeled 2 light-years. The length of the scale bar is a little less than one-eighth the total width of the image. Below the image is a color key showing which NIRCam filters were used to create the image and which visible-light color is assigned to each filter. From left to right, NIRCam filters are: F187N is blue; F444W is green; and F470N is red.
Color Info
Color InfoA brief description of the methods used to convert telescope data into the color image being presented.

These images are a composite of separate exposures acquired by the James Webb Space Telescope using the NIRCam instrument. Several filters were used to sample narrow and broad wavelength ranges. The color results from assigning different hues (colors) to each monochromatic (grayscale) image associated with an individual filter. In this case, the assigned colors are:   Red: F470N, Green: F444W, Blue: F187N
