Cat’s Paw (NIRCam) Compass Image

Image titled “James Webb Space Telescope; Cat’s Paw Nebula; NGC 6334,” with compass arrows, scale bar, and color key. This portion of the star-forming region contains four roughly circular areas composed of gas, dust, and young stars. Each circular area has a luminous blue glow. Many small, yellow-white stars are spread across the scene, and a few larger blue-white stars are scattered throughout. At the bottom left is a scale bar labeled 1.6 light-years. The length of the scale bar is about one sixth of the total image. At the bottom right are compass arrows indicating the orientation of the image on the sky. The east arrow points toward 12 o’clock. The north arrow points in the 3 o’clock direction. Below the image is a color key showing which NIRCam filters were used to create the image and which visible-light color is assigned to each filter. From left to right: F090W is blue, F187N is cyan, F200W is green, F277W is yellow, F335M is orange, and F470N is red.

This image of the Cat’s Paw Nebula, captured by the James Webb Space Telescope’s NIRCam (Near-Infrared Camera), shows compass arrows, scale bar, and color key for reference.

The north and east compass arrows show the orientation of the image on the sky. Note that the relationship between north and east on the sky (as seen from below) is flipped to the direction arrows on a map of the ground (as seen from above).

The scale bar is labeled in light-years, which is the distance that light travels in one Earth-year. (It takes 1.6 years for light to travel a distance equal to the length of the scale bar.) One light-year is equal to about 5.88 trillion miles or 9.46 trillion kilometers.

This image shows invisible near-infrared wavelengths of light that have been translated into visible-light colors. The color key shows which NIRCam filters were used when collecting the light. The color of each filter name is the visible light color used to represent the infrared light that passes through that filter.

Read a full description of the image.

About the Object

  • R.A. Position
    R.A. PositionRight ascension – analogous to longitude – is one component of an object's position.
    17:20:41.87
  • Dec. Position
    Dec. PositionDeclination – analogous to latitude – is one component of an object's position.
    -35:49:36.15
  • Constellation
    ConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.
    Scorpius
  • Distance
    DistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.
    5,500 light-years
  • Dimensions
    DimensionsThe physical size of the object or the apparent angle it subtends on the sky.
    Image is 5.8 arcmin across (about 9.3 light-years)

About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.

    This image was created with Webb data from proposal: 6778 (M. Garcia Marin). Image processing: Joseph DePasquale (STScI).

  • Instrument
    InstrumentThe science instrument used to produce the data.
    NIRCam
  • Exposure Dates
    Exposure DatesThe date(s) that the telescope made its observations and the total exposure time.
    6 September 2024
  • Filters
    FiltersThe camera filters that were used in the science observations.
    F090W, F187N, F200W, F277W, F335M, F470N
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    Cat's Paw Nebula, NGC 6334
  • Object Description
    Object DescriptionThe type of astronomical object.
    Massive star forming region
  • Release Date
    July 10, 2025
  • Science Release
    NASA’s Webb Scratches Beyond Surface of Cat’s Paw for 3rd Anniversary
    Read the release
  • Credit
    Image: NASA, ESA, CSA, STScI

Downloads

  • Full Res (For Display), 11055 × 14493
    png (173.51 MB)
  • Full Res (For Print), 11055 × 14493
    tif (173.91 MB)
  • Full Res (JPG), 11055 × 14493
    jpg (30.97 MB)
  • 1526 × 2000
    jpg (1.16 MB)
Image titled “James Webb Space Telescope; Cat’s Paw Nebula; NGC 6334,” with compass arrows, scale bar, and color key. This portion of the star-forming region contains four roughly circular areas composed of gas, dust, and young stars. Each circular area has a luminous blue glow. Many small, yellow-white stars are spread across the scene, and a few larger blue-white stars are scattered throughout. At the bottom left is a scale bar labeled 1.6 light-years. The length of the scale bar is about one sixth of the total image. At the bottom right are compass arrows indicating the orientation of the image on the sky. The east arrow points toward 12 o’clock. The north arrow points in the 3 o’clock direction. Below the image is a color key showing which NIRCam filters were used to create the image and which visible-light color is assigned to each filter. From left to right: F090W is blue, F187N is cyan, F200W is green, F277W is yellow, F335M is orange, and F470N is red.
Color Info
Color InfoA brief description of the methods used to convert telescope data into the color image being presented.

These images are a composite of separate exposures acquired by the James Webb Space Telescope using the NIRCam instrument. Several filters were used to sample specific wavelength ranges. The color results from assigning different hues (colors) to each monochromatic (grayscale) image associated with an individual filter. In this case, the assigned colors are:   Blue: F090W, Cyan: F187N, Green: F200W, Yellow: F277W, Orange: F335M, Red: F444W
