Serpens (NIRCam Image)

A rectangular image with black vertical rectangles at the bottom left and top right to indicate missing data. A young star-forming region is filled with wispy orange, red, and blue layers of gas and dust. The upper left corner of the image is filled with mostly orange dust, and within that orange dust, there are several small red plumes of gas that extend from the top left to the bottom right, at the same angle. The center of the image is filled with mostly blue gas. At the center, there is one particularly bright star, that has an hourglass shadow above and below it. To the right of that is what looks a vertical eye-shaped crevice with a bright star at the center. The gas to the right of the crevice is a darker orange. Small points of light are sprinkled across the field, brightest sources in the field have extensive eight-pointed diffraction spikes that are characteristic of the Webb Telescope.

In this image of the Serpens Nebula from the Near-Infrared Camera (NIRCam) on NASA’s James Webb Space Telescope, astronomers found a grouping of aligned protostellar outflows within one small region (the top left corner). In the Webb image, these jets are signified by bright clumpy streaks that appear red, which are shockwaves from the jet hitting surrounding gas and dust.

The Serpens Nebula, located 1,300 light-years from Earth, is home to a particularly dense cluster of newly forming stars (~100,000 years old), some of which will eventually grow to the mass of our Sun.

This region has been home to other coincidental discoveries, including the flapping “Bat Shadow,” which earned its name when 2020 data from NASA’s Hubble Space Telescope revealed a shadow from a star’s planet-forming disk to flap, or shift. This feature is visible at the center of the Webb image.

To the right of the “Bat Shadow” lies another intriguing feature—an eye-shaped crevice, which appears as if a star is bursting through. However, astronomers say looks may be deceiving here. This could just be gases of different densities layered on top of one another, similar to what is seen in the famous Pillars of Creation.

And to the right of that, an extremely dark patch could be a similar occurrence. This gas and dust are so dense in comparison to the rest of the region, no near-infrared light is getting through.

About the Object

  • R.A. Position
    R.A. PositionRight ascension – analogous to longitude – is one component of an object's position.
    18:29:56.91
  • Dec. Position
    Dec. PositionDeclination – analogous to latitude – is one component of an object's position.
    +1:14:45.77
  • Constellation
    ConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.
    Serpens
  • Distance
    DistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.
    1,300 light-years
  • Dimensions
    DimensionsThe physical size of the object or the apparent angle it subtends on the sky.
    Image is about 6.3 arcminutes across (1.8 light-years)

About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.

    The Webb observations include those from program 1611 (K. Pontoppidan). Image Processing: Alyssa Pagan (STScI)



  • Instrument
    InstrumentThe science instrument used to produce the data.
    NIRCam
  • Exposure Dates
    Exposure DatesThe date(s) that the telescope made its observations and the total exposure time.
    26 April 2023, 12 May 2023
  • Filters
    FiltersThe camera filters that were used in the science observations.
    F140M, F210M, F360M, F480M
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    Serpens Nebula, HBC 672, [EC 92] 82
  • Object Description
    Object DescriptionThe type of astronomical object.
    Reflection nebula and star forming region
  • Release Date
    June 20, 2024
  • Science Release
    First-of-Its-Kind Detection Made in Striking New Webb Image
    Read the release
  • Credit
    Image: NASA, ESA, CSA, STScI, Klaus Pontoppidan (NASA-JPL), Joel Green (STScI)

Downloads

  • Full Res (For Print), 12682 × 8036
    tif (107.53 MB)
  • Full Res (For Display), 12682 × 8036
    png (115.05 MB)
  • 2000 × 1267
    png (2.82 MB)
A rectangular image with black vertical rectangles at the bottom left and top right to indicate missing data. A young star-forming region is filled with wispy orange, red, and blue layers of gas and dust. The upper left corner of the image is filled with mostly orange dust, and within that orange dust, there are several small red plumes of gas that extend from the top left to the bottom right, at the same angle. The center of the image is filled with mostly blue gas. At the center, there is one particularly bright star, that has an hourglass shadow above and below it. To the right of that is what looks a vertical eye-shaped crevice with a bright star at the center. The gas to the right of the crevice is a darker orange. Small points of light are sprinkled across the field, brightest sources in the field have extensive eight-pointed diffraction spikes that are characteristic of the Webb Telescope.
Color Info
Color InfoA brief description of the methods used to convert telescope data into the color image being presented.

This image is a composite of separate exposures acquired by the James Webb Space Telescope using the NIRCam instrument. Several filters were used to sample medium wavelength ranges. The color results from assigning different hues (colors) to each monochromatic (grayscale) image associated with an individual filter. In this case, the assigned colors are:  Blue: F140M, Cyan: F210M, Orange: F360M, Red: 480M

Compass and Scale
Compass and ScaleAn astronomical image with a scale that shows how large an object is on the sky, a compass that shows how the object is oriented on the sky, and the filters with which the image was made.
