Russia’s Volga River is the largest river system in Europe, draining over 1.3 million square kilometers of catchment area into the Caspian Sea. The brackish Caspian is Earth’s largest landlocked water body, and its isolation from the world’s oceans has enabled the preservation of several unique animal and plant species. The Volga provides most of the Caspian’s fresh water and nutrients, and also discharges large amounts of sediment and industrial waste into the relatively shallow northern part of the sea. These images of the region were captured by the Multi-angle Imaging SpectroRadiometer (MISR) on October 5, 2001, during Terra orbit 9567.
The natural color image is from MISR’s nadir (vertical-viewing) camera, and shows how light is reflected at red, green, and blue wavelengths. The multiple viewing angle image is a false color composite of red-band imagery from MISR’s 60-degree backward, nadir, and 60-degree forward-viewing cameras, displayed as red, green, and blue, respectively. Here, color variations indicate how light is reflected at different angles of view. Water appears blue in this image, for example, because sun glitter makes smooth, wet surfaces look brighter at the forward camera’s view angle. The rougher-textured vegetated wetlands near the coast exhibit preferential backscattering, and consequently appear reddish. A small cloud near the center of the delta separates into red, green, and blue components due to geometric parallax associated with its elevation above the surface.
Other notable features within the images include several linear features located near the Volga Delta shoreline. These long, thin lines are artificially maintained shipping channels, dredged to depths of at least 2 meters.
References & Resources
Image courtesy NASA/GSFC/LaRC/JPL, MISR Team.
