Outflow Channels Emptying into Northern Plains of Chryse Planitia

The channel system in the upper half of the image is Maja Valles. The channels appear to have been carved by flowing water released from Juventae Chasma a chaotic depression that is located several hundred kilometers to the south.
March 19, 2014
CreditNASA/JPL-Caltech
Language
  • english

The channel system in the upper half of the image is Maja Valles, which averages 10 kilometers wide, 1 kilometer deep, and extends for about 180 kilometers. The channels appear to have been carved by flowing water released from Juventae Chasma (2°S,61°W), a 250 × 100-kilometer chaotic depression that is located several hundred kilometers to the south. The channel system in the lower half of the image is Vedra Valles. Both channel systems start in and cut into the old cratered surface of Lunae Planum and discharge into the younger plains of Chryse Planitia, shown on the right side of the image. The area shown is 225 kilometers across.
