Compass and Scale Image for Ring Nebula (HST and LBT)
About the Object
- R.A. PositionR.A. PositionRight ascension – analogous to longitude – is one component of an object's position.18h 53m 35.07s
- Dec. PositionDec. PositionDeclination – analogous to latitude – is one component of an object's position.33° 1' 45.03"
- ConstellationConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.Lyra
- DistanceDistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.2,300 light-years (700 parsecs)
About the Data
- Data DescriptionData DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.The image was created from Hubble data from proposal 12309: C. R. O'Dell (Vanderbilt University), G. Ferland (University of Kentucky), and W. Henney and M. Peimbert (UNAM). - InstrumentInstrumentThe science instrument used to produce the data.HST>WFC3/UVIS and Large Binocular Telescope (LBT)
- Exposure DatesExposure DatesThe date(s) that the telescope made its observations and the total exposure time.HST: September 19, 2011; LBT: June 6, 2010
- FiltersFiltersThe camera filters that were used in the science observations.WFC3/UVIS: F469N (He II), F502N ([O III]), and F658N ([N II]) LBT: H2, 2.1 microns
- Object NameObject NameA name or catalog number that astronomers use to identify an astronomical object.Ring Nebula, M57, NGC 6720
- Object DescriptionObject DescriptionThe type of astronomical object.Planetary Nebula
- Release DateMay 23, 2013
- Science ReleaseNASA’s Hubble Space Telescope Reveals the Ring Nebula’s True Shape
- Credit
Blue: F469N (He II) Green: F502N ([O III]) Red/orange: F658N ([N II]) Red: H2, 2.1 microns
