Hubble Image Overlaid on Modeling of Apollo 17 Landing Site

Hubble Image Overlaid on Modeling of Apollo 17 Landing Site
This image was constructed by overlaying the Hubble Advanced Camera for Surveys image of the Apollo 17 landing region within the Taurus-Littrow valley, taken on Dec. 16, 2005, with a digital-terrain model acquired by the Apollo program to provide a perspective view looking from west to east up the valley. These Hubble data illustrate the high-resolution resolving power of the Advanced Camera for Surveys and display features smaller than a soccer field from low-Earth orbit some 248,000 miles (400,000 kilometers) distant. These images were acquired at nearly full Moon, so the long, dark shadows typical of many lunar orbital photos are not seen; however, this is perfect lighting for color analysis from which to interpret subtle compositional differences. The Hubble Space Telescope Lunar Exploration team is using the Apollo 17 images (and those acquired of the Apollo 15 site) as "ground-truth" in an effort to discriminate lunar materials enriched in ilmenite, a titanium-bearing oxide of potential value as a resource in human exploration of the Moon. The image was processed by the Hubble Space Telescope Lunar Exploration team at NASA's Goddard Space Flight Center, Northwestern University, and the Space Telescope Science Institute.

About the Object

  • Distance
    DistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.
    The Moon is 238,857 miles (384,403 kilometers) from the Earth.
  • Dimensions
    DimensionsThe physical size of the object or the apparent angle it subtends on the sky.
    The Moon has a diameter of 2160 miles (3476 kilometers).

About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.
    These HST data are from proposal 10719. NASA's HST Lunar observation team is led by Chief Scientist J. Garvin. The team includes M. Robinson (Northwestern Univ.), D. Skillman (NASA/GSFC), B. Hapke (Univ. of Pittsburgh), C. Pieters (Brown Univ.), M. Ulmer (Northwestern Univ.), J. Bell (Cornell Univ.), and J. Taylor (Univ. of Hawaii).
  • Instrument
    InstrumentThe science instrument used to produce the data.
    HST>ACS/HRC with Apollo 17
  • Exposure Dates
    Exposure DatesThe date(s) that the telescope made its observations and the total exposure time.
    August 16, 2005
  • Filters
    FiltersThe camera filters that were used in the science observations.
    HST: F250W (250nm), F344N (344nm), F502N (502nm), F658N (658nm)
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    moon
  • Object Description
    Object DescriptionThe type of astronomical object.
    Earth's Satellite
  • Release Date
    October 19, 2005
  • Science Release
    NASA’s Hubble Looks for Possible Moon Resources
    Read the release
  • Credit
    NASA, ESA, and J. Garvin (NASA/GSFC)
