Hubble Views of Dimorphos Ejecta

Image is three columns, each column is a photo with a black background, a bright blue spot is at center. In the panel column all the way to the left, noted as 22 minutes after impact, the center bright spot only has a small amount of dusty haze and only a few spikes closely surrounding it.In the middle column, noted as 5 hours after impact, the haze around the blue dot has expanded wider out with additional spikes and haze.In the column to the left, noted as 8.2 hours after impact, the haze around the blue dot spreads even further, with wisps expanding to the bottom left of the image.

These images from NASA’s Hubble Space Telescope, taken 22 minutes, 5 hours, and 8.2 hours after NASA’s Double Asteroid Redirection Test (DART) intentionally impacted Dimorphos, show expanding plumes of ejecta from the asteroid’s body. This event was the world’s first test of the kinetic impact technique using a spacecraft to deflect an asteroid by modifying its orbit.

The Hubble images show ejecta from the impact that appear as rays stretching out from the body of the asteroid. The bolder, fanned-out spike of ejecta to the left of the asteroid is in the general direction from which DART approached. In the Hubble images, astronomers estimate that the brightness of the Didymos system increased by 3 times after impact. They’re also particularly intrigued by how that brightness then held steady, even eight hours after impact.

These observations, when combined with data from NASA’s James Webb Space Telescope, will allow scientists to gain knowledge about the nature of the surface of Dimorphos, how much material was ejected by the collision, how fast it was ejected, and the distribution of particle sizes in the expanding dust cloud.

Hubble will observe the Didymos-Dimorphos system ten more times over the next three weeks to monitor how the ejecta cloud expands and fades over time.

Hubble observations were conducted in one filter, WFC3/UVIS F350LP, and assigned the color blue.

About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.

    This image was created from HST data from proposal: 16674 (J. Li).

  • Instrument
    InstrumentThe science instrument used to produce the data.
    WFC3/UVIS
  • Exposure Dates
    Exposure DatesThe date(s) that the telescope made its observations and the total exposure time.
    26-27 Sept 2022
  • Filters
    FiltersThe camera filters that were used in the science observations.
    F350LP
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    Dimorphos
  • Object Description
    Object DescriptionThe type of astronomical object.
    Double Asteroid Redirection Test (DART) on asteroid Dimorphos
  • Release Date
    September 29, 2022
  • Science Release
    Webb, Hubble Capture Detailed Views of DART Impact
    Read the release
  • Credits
    NASA, ESA, Jian-Yang Li (PSI); Image Processing: Alyssa Pagan (STScI)

Downloads

  • Full Res (For Print), 1320 × 440
    tif (720.91 KB)
  • Full Res (For Display), 1320 × 440
    png (670.29 KB)
Image is three columns, each column is a photo with a black background, a bright blue spot is at center. In the panel column all the way to the left, noted as 22 minutes after impact, the center bright spot only has a small amount of dusty haze and only a few spikes closely surrounding it.In the middle column, noted as 5 hours after impact, the haze around the blue dot has expanded wider out with additional spikes and haze.In the column to the left, noted as 8.2 hours after impact, the haze around the blue dot spreads even further, with wisps expanding to the bottom left of the image.
Color Info
Color InfoA brief description of the methods used to convert telescope data into the color image being presented.

The images are separate exposures acquired by the WFC3 instrument on the Hubble Space Telescope. The color results from assigning a blue hue to a monochromatic (grayscale) image.
