Westerlund 2: 3D Tactile Print

This illustration shows the Westerlund 2 image and the 3D tactile print derived from the Hubble Space Telescope data.

The tactile print was provided by the 3D Astronomy Project at STScI which makes star cluster and galaxy imagery available in 3D tactile representations outfitted with textures to distinguish specific features in the celestial object. The 3D prints are produced through an innovative process [Christian et al. 2015, Grice et al. 2015] for the star clusters Westerlund 2 [Zeidler 2015], NGC 602 and others as well as several LEGUS galaxies.

The purpose is to stimulate an understanding of and interest in astronomical phenomena for any person, but especially persons with blindness or visual impairment (B/VI) and individuals who are tactile learners. 3D Astronomy does address the need for assistive materials for individuals with B/VI in particular. 3D prints of Hubble astronomical data are produced using the research analysis of the observations and transforming the science data into 3D prints.

Image intensity is used as a surrogate for the mass distribution and textures are used to distinguish various features in the astronomical objects. Customarily, in visualization images, intensity and colors are used to highlight the astrophysics and so intensity and color are transformed into print "elevation" and colors into textures.

For a star cluster such as Westerlund 2, a "2.5 D" image is produced considering that much of a star cluster's central region can be tenuous gas, which is difficult to print, as structure holding the stars in place are difficult to interpret for visually impaired individuals. Print files in STL format from 3D Astronomy are released periodically.
