Terzan 5 (Webb and Hubble Compass Image)

Image titled “James Webb and Hubble Space Telescopes; Terzan 5,” with compass arrows and color key. A dramatically crowded starfield that looks like a just-shaken snow globe. The black background of space is covered by thousands of tiny white, orange, and blue points of light, which are stars. The stars are most concentrated in the center, forming a roughly circular orb. At the bottom left are compass arrows indicating the orientation of the image on the sky. The east arrow points toward 12 o’clock. The north arrow points toward 3 o’clock. At the bottom right is a scale bar labeled 2 light-years. The length of the scale bar is about one seventh of the total image. Below the image is a color key showing which Hubble ACS/WFC and Webb NIRCam filters were used to create the image, and which visible-light color is assigned to each filter. Hubble ACS filters, from left to right: F606W is blue and F814W is teal. Webb NIRCam filters: F115W is orange, F200W is red.

This image of bulge fossil fragment Terzan 5 was captured by the James Webb and Hubble space telescopes. Webb’s data are from its NIRCam (Near-Infrared Camera) and Hubble’s from its Advanced Camera for Surveys (ACS).

The image shows a scale bar, compass arrows, and color key for reference.

The scale bar is labeled in light-years along the bottom, which is the distance that light travels in one Earth-year. (It takes two years for light to travel a distance equal to the length of the scale bar.) One light-year is equal to about 5.88 trillion miles or 9.46 trillion kilometers.

The north and east compass arrows show the orientation of the image on the sky. Note that the relationship between north and east on the sky (as seen from below) is flipped relative to direction arrows on a map of the ground (as seen from above).

This image shows visible and near-infrared wavelengths of light that have been translated into visible-light colors. The color key shows which NIRCam and ACS filters were used when collecting the light. The color of each filter name is the visible-light color used to represent the infrared light that passes through that filter.

Read the full image caption.

About the Object

  • R.A. Position
    R.A. PositionRight ascension – analogous to longitude – is one component of an object's position.
    17:48:05.00
  • Dec. Position
    Dec. PositionDeclination – analogous to latitude – is one component of an object's position.
    -24:46:48.0
  • Constellation
    ConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.
    Sagittarius
  • Distance
    DistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.
    22,000 light-years away
  • Dimensions
    DimensionsThe physical size of the object or the apparent angle it subtends on the sky.
    This image is about 2.1 arcminutes across (13 light-years)

About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.

    This image was created with Hubble data from proposal: 12933 (F. R. Ferraro) and Webb data from proposal: 5502 (F. R. Ferraro).

  • Instrument
    InstrumentThe science instrument used to produce the data.
    Hubble> ACS/WFC Webb> NIRCam
  • Exposure Dates
    Exposure DatesThe date(s) that the telescope made its observations and the total exposure time.
    19 Sept. 2024, 30 April-18 August 2013
  • Filters
    FiltersThe camera filters that were used in the science observations.
    F606W, F814W, F115W, F200W
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    Terzan 5
  • Object Description
    Object DescriptionThe type of astronomical object.
    Bulge fossil fragment stellar group
  • Release Date
    June 16, 2026
  • Science Release
    NASA Webb, Hubble Reveal History of Relic of Milky Way’s Formation
    Read the release
  • Credit
    Image: NASA, ESA, CSA, STScI, Giorgia Zullo (University of Bologna), Francesco Ferraro (University of Bologna); Image Processing: Alyssa Pagan (STScI)

Downloads

  • Full Res (For Print), 4144 × 4120
    tif (19.54 MB)
  • Full Res (For Display), 4144 × 4120
    png (19.98 MB)
  • 4144 × 4120
    jpg (11.06 MB)
  • 2000 × 1988
    jpg (3.7 MB)
Image titled “James Webb and Hubble Space Telescopes; Terzan 5,” with compass arrows and color key. A dramatically crowded starfield that looks like a just-shaken snow globe. The black background of space is covered by thousands of tiny white, orange, and blue points of light, which are stars. The stars are most concentrated in the center, forming a roughly circular orb. At the bottom left are compass arrows indicating the orientation of the image on the sky. The east arrow points toward 12 o’clock. The north arrow points toward 3 o’clock. At the bottom right is a scale bar labeled 2 light-years. The length of the scale bar is about one seventh of the total image. Below the image is a color key showing which Hubble ACS/WFC and Webb NIRCam filters were used to create the image, and which visible-light color is assigned to each filter. Hubble ACS filters, from left to right: F606W is blue and F814W is teal. Webb NIRCam filters: F115W is orange, F200W is red.
Color Info
Color InfoA brief description of the methods used to convert telescope data into the color image being presented.

These images were acquired by the ACS/WFC instrument on Hubble and the NIRCam instrument on Webb. The color results from assigning different hues (colors) to a monochromatic (grayscale) image. In this case, the assigned colors are: Blue: F606W, Cyan: F814W, Orange: F115W, Red: F200W
