Crab Nebula in Multiple Wavelengths
This highly detailed image of the Crab Nebula was assembled by combining data from five telescopes spanning nearly the entire breadth of the electromagnetic spectrum: The Very Large Array (radio) in red; Spitzer Space Telescope (infrared) in yellow; Hubble Space Telescope (visible) in green; XMM-Newton (ultraviolet) in blue; and Chandra X-ray Observatory (X-ray) in purple.
The Hubble visible-light image offers a very sharp view of hot filamentary structures that permeate this nebula. The infrared image includes the glow of dust particles absorbing ultraviolet and visible light, and re-radiating at lower energies (longer wavelengths) in the infrared. An energetic cloud of electrons driven by a rapidly rotating neutron star, or pulsar, at its core glows brightly in ultraviolet radiation and X-rays. The neutron star’s fierce "wind" of charged particles energized the nebula, causing it to emit the radio waves. In this color scheme used for this set of images the background stars appear blue because they have the strongest signal in the ultraviolet-light exposure.
The Crab Nebula, the result of a supernova explosion seen by Chinese and other astronomers in the year 1054, is 6,500 light-years from Earth.
About the Object
- R.A. PositionR.A. PositionRight ascension – analogous to longitude – is one component of an object's position.05h 34m 31.94s
- Dec. PositionDec. PositionDeclination – analogous to latitude – is one component of an object's position.+22° 00' 52.2"
- ConstellationConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.Taurus
- DistanceDistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.6,500 light-years (2,000 parsecs)
- Object NameObject NameA name or catalog number that astronomers use to identify an astronomical object.Crab Nebula, M1, NGC 1952
- Object DescriptionObject DescriptionThe type of astronomical object.Supernova remnant
- Release DateMay 10, 2017
- Science ReleaseObservatories Combine to Crack Open the Crab Nebula
- Credits
Red: VLA Radio Yellow: SST Infrared Green: HST Optical Blue: XMM Ultraviolet Purple: CXO X-ray
