Hubble Images Outbursts from Massive Star
These NASA Hubble Space Telescope images show the outflow from one of the brightest hypergiant stars in the sky, VY Canis Majoris.
The image on the left, taken with Hubble's Wide Field and Planetary Camera 2, reveal its complex circumstellar ejecta, with arcs, filaments, and knots of material formed by the massive outflows. This image provided the first evidence that the brightest arcs and knots were created during several outbursts. The random orientations of the arcs also suggested they were produced by localized eruptions from active regions on the star's surface. This is composite picture from separate images taken in blue, green, red, and near-infrared light.
The image at right, taken with the Advanced Camera for Surveys, was made with polarizing filters to show how the dust ejected by the star is distributed in three-dimensional space. The light from the star becomes polarized when it is reflected off the dust. The dust formed around the star and was driven into space. To see the polarized light, astronomers used a polarizing filter, which lets through only light vibrating in one direction and blocks out light vibrating in other directions. Astronomers assembled this picture from separate images taken at three different polarization angles, colored red, green, and blue.
They measured the velocities of the ejecta from spectra obtained with the Keck 10-meter telescope. They also compared the ejecta's expansion taken with Hubble six years apart. These observations showed that the numerous arcs, loops, and knots were moving at different speeds and in various directions, confirming they were produced from separate events and from different locations on the star. The prominent arc to the northwest or upper right in the Hubble image is moving at 102,700 miles an hour (165,600 kilometers an hour), and was ejected about 500 years ago. The knots near the center of the image are traveling at 80,400 miles an hour (129,600 kilometers an hour).
The star, located 5,000 light-years away, is one of the largest and one of the most luminous evolved stars known. It is 500,000 times brighter and about 30 to 40 times more massive than the Sun.
The Wide Field and Planetary Camera 2 observations were taken March 22, 1999 and June 13, 2005. The Advanced Camera for Surveys images were taken Aug. 17, 2004.
About the Object
- R.A. PositionR.A. PositionRight ascension – analogous to longitude – is one component of an object's position.07h 22m 58.33s
- Dec. PositionDec. PositionDeclination – analogous to latitude – is one component of an object's position.-25° 46' 3.2"
- ConstellationConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.Canis Major
- DistanceDistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.Approximately 5,000 light-years (1.5 kiloparsecs)
- DimensionsDimensionsThe physical size of the object or the apparent angle it subtends on the sky.Roughly 35 arcseconds (0.85 light-years or 0.25 parsecs) across
About the Data
- Data DescriptionData DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.The Hubble image was created from HST data from proposals: 7304: R. Humphreys, K. Davidson, T. Jones, and R. Gehrz (University of Minnesota) and J. Krautter and T. Szeifert (Landessternwarte, Heidelberg) 10262: R. Humphreys and T. Jones (University of Minnesota), G. Herbig (University of Hawaii), and G. Wallerstein (University of Washington). - InstrumentInstrumentThe science instrument used to produce the data.HST>WFPC2 (left) and HST>ACS/HRC (right)
- Exposure DatesExposure DatesThe date(s) that the telescope made its observations and the total exposure time.March 22, 1999 and June 13, 2005 (left); August 17, 2004 (right)
- FiltersFiltersThe camera filters that were used in the science observations.WFPC2: F410M (Strömgren v), F656N (H-alpha), F547M (Strömgren y), and F1042M ACS: F658N (H-alpha) (POL0V, POL60V, and POL120V) and F550M(V) (POL0V, POL60V, and POL120V)
- Object NameObject NameA name or catalog number that astronomers use to identify an astronomical object.VY Canis Majoris
- Object DescriptionObject DescriptionThe type of astronomical object.Variable Star with Circumstellar Nebula
- Release DateJanuary 8, 2007
- Science ReleaseAstronomers Map a Hypergiant Star’s Massive Outbursts
- Credit
The left is a composite of many separate exposures made by the WFPC2 instrument on the Hubble Space Telescope using several different filters. Three filters were used to sample various wavelength ranges in each instrument. The color results from assigning different hues (colors) to each monochromatic image. In this case, the assigned colors are: Blue: F410M (Strömgren v) Green: F547M (Strömgren y) Red: F656N (H-alpha) + F1042M The right image is a composite of many separate exposures made by the ACS instruments on the Hubble Space Telescope using several different filters. Three filters were used to sample various wavelength ranges in each instrument. The color results from assigning different hues (colors) to each monochromatic image. In this case, the assigned colors are: Cyan: F550M (V) + POL0V Yellow: F550M(V) + POL60V Red: F550M(V) + POL120V
