Multiwavelength OPAL Jupiter

A two-panel image labeled "Jupiter, January 5, 2024, HST WFC3/UVIS" showcases the wealth of information provided by the spectral filters on the Hubble's Wide Field Camera 3 (WFC3) science instrument. At left, the Hubble image of Jupiter is created using three filters at wavelengths similar to the colors seen by the human eye: F395N is blue, F502N is green, F658N is red. At right, the wavelength bounds are widened beyond the visible range to extend just into the ultraviolet (UV) and infrared regimes: F343N is blue, F467M is green, FQ889N is red. Humans can't perceive these extended wavelengths. The result is a vivid disk that shows UV-absorbing lofty hazes as orange (over the poles and in three large storms, including the Great Red Spot), and freshly-formed ice as white (compact storm plumes just north of the equator). These filters (and others not shown here) allow astronomers to study differences in cloud thickness, altitude, and chemical makeup.

Two views of Jupiter showcase the wealth of information provided by the spectral filters on the Hubble Space Telescope's Wide Field Camera 3 (WFC3) science instrument. At left, the RGB composite is created using three filters at wavelengths similar to the colors seen by the human eye. At right, the wavelength bounds are widened beyond the visible range to extend just into the ultraviolet (UV) and infrared regimes. Humans cannot perceive these extended wavelengths, but some animals (such as mantis shrimp, whose eyes function similarly to certain sensors on some NASA missions) are able to detect infrared and ultraviolet light. The result is a vivid disk that shows UV-absorbing lofty hazes as orange (over the poles and in three large storms, including the Great Red Spot), and freshly-formed ice as white (compact storm plumes just north of the equator). Astronomers, including the OPAL team, use these filters (and others not shown here) to study differences in cloud thickness, altitude, and chemical makeup.







About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.

    The HST observations include those from the OPAL observing programs (A. Simon)

  • Instrument
    InstrumentThe science instrument used to produce the data.
    WFC3/UVIS
  • Filters
    FiltersThe camera filters that were used in the science observations.
    F395N, F502N, F658N, F343N, F467M, FQ889N
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    Jupiter
  • Object Description
    Object DescriptionThe type of astronomical object.
    Gas giant planet
  • Release Date
    December 9, 2024
  • Science Release
    NASA’s Hubble Celebrates Decade of Tracking Outer Planets
    Read the release
  • Credit
    NASA, ESA, Amy Simon (NASA-GSFC), Michael H. Wong (UC Berkeley); Image Processing: Joseph DePasquale (STScI)

Downloads

  • Full Res (For Display), 2628 × 1313
    png (2.26 MB)
  • Full Res (For Print), 2628 × 1313
    tif (2.54 MB)
  • 2000 × 999
    jpg (340.6 KB)
  • Unannotated - Full Res (For Display), 2628 × 1313
    png (2.24 MB)
  • Unannotated - Full Res (For Print), 2628 × 1313
    tif (2.52 MB)
  • Unannotated, 2000 × 999
    jpg (312.76 KB)
A two-panel image labeled "Jupiter, January 5, 2024, HST WFC3/UVIS" showcases the wealth of information provided by the spectral filters on the Hubble's Wide Field Camera 3 (WFC3) science instrument. At left, the Hubble image of Jupiter is created using three filters at wavelengths similar to the colors seen by the human eye: F395N is blue, F502N is green, F658N is red. At right, the wavelength bounds are widened beyond the visible range to extend just into the ultraviolet (UV) and infrared regimes: F343N is blue, F467M is green, FQ889N is red. Humans can't perceive these extended wavelengths. The result is a vivid disk that shows UV-absorbing lofty hazes as orange (over the poles and in three large storms, including the Great Red Spot), and freshly-formed ice as white (compact storm plumes just north of the equator). These filters (and others not shown here) allow astronomers to study differences in cloud thickness, altitude, and chemical makeup.
Color Info
Color InfoA brief description of the methods used to convert telescope data into the color image being presented.

These images are a composite of separate exposures acquired by the WFC3 instrument on the Hubble Space Telescope. Several filters were used to sample medium wavelength ranges. The color results from assigning different hues (colors) to each monochromatic (grayscale) image associated with an individual filter. In this case, the assigned colors are: Blue: F395N & F343N, Green: F502N & F467M, Red: F658N & FQ889N
