The Pencil Nebula: Remnants of an Exploded Star (NGC 2736)

Gaseous filaments in shades of orange and green cross the frame from upper left to lower right.

Remnants from a star that exploded thousands of years ago created a celestial abstract portrait, as captured in this NASA Hubble Space Telescope image of the Pencil Nebula.

Officially known as NGC 2736, the Pencil Nebula is part of the huge Vela supernova remnant, located in the southern constellation Vela. Discovered by Sir John Herschel in the 1840s, the nebula's linear appearance triggered its popular name. The nebula's shape suggests that it is part of the supernova shock wave that recently encountered a region of dense gas. It is this interaction that causes the nebula to glow, appearing like a rippled sheet.

In this snapshot, astronomers are looking along the edge of the undulating sheet of gas. This view shows large, wispy filamentary structures, smaller bright knots of gas, and patches of diffuse gas. The Hubble Heritage Team used the Advanced Camera for Surveys in October 2002 to observe the nebula. The region of the Pencil Nebula captured in this image is about three fourths of a light-year across. The Vela supernova remnant is 114 light-years (35 parsecs) across. The remnant is about 815 light-years (250 parsecs) away from our solar system.

The nebula's luminous appearance comes from dense gas regions that have been struck by the supernova shock wave. As the shock wave travels through space [from right to left in the image], it rams into interstellar material. Initially the gas is heated to millions of degrees, but then subsequently cools down, emitting the optical light visible in the image.

The colors of the various regions in the nebula yield clues about this cooling process. Some regions are still so hot that the emission is dominated by ionized oxygen atoms, which glow blue in the picture. Other regions have cooled more and are seen emitting red in the image (cooler hydrogen atoms). In this situation, color shows the temperature of the gas. The nebula is visible in this image because it is glowing.

The supernova explosion left a spinning pulsar at the core of the Vela region. Based on the rate at which the pulsar is slowing down, astronomers estimate that the explosion may have occurred about 11,000 years ago. Although no historical records of the blast exist, the Vela supernova would have been 250 times brighter than Venus and would have been easily visible to southern observers in broad daylight. The age of the blast, if correct, would imply that the initial explosion pushed material from the star at nearly 22 million miles per hour. As the Vela supernova remnant expands, the speed of its moving filaments, such as the Pencil Nebula, decreases. The Pencil Nebula, for example, is moving at roughly 400,000 miles per hour.

About the Object

  • R.A. Position
    R.A. PositionRight ascension – analogous to longitude – is one component of an object's position.
    09h 0m 17.71s
  • Dec. Position
    Dec. PositionDeclination – analogous to latitude – is one component of an object's position.
    -45° 54' 57.27"
  • Constellation
    ConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.
    Vela
  • Distance
    DistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.
    About 815 light-years (250 parsecs)
  • Dimensions
    DimensionsThe physical size of the object or the apparent angle it subtends on the sky.
    The image is roughly 3.3 arcminutes (0.78 light-years or 0.24 parsecs) across.

About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.
    These data are from the HST proposal 9698 by K. Noll, H. Bond, C. Christian, L. Frattare, F. Hamilton, Z. Levay, T. Royle (Hubble Heritage Team STScI/AURA) and collaborators W. Blair (JHU) and D. Malin (DMI).
  • Instrument
    InstrumentThe science instrument used to produce the data.
    HST>ACS/WFC
  • Exposure Dates
    Exposure DatesThe date(s) that the telescope made its observations and the total exposure time.
    October 21, 2002, Exposure Time: 3 hours
  • Filters
    FiltersThe camera filters that were used in the science observations.
    F435W (B), F502N ([O III]), F555W (V), F658N (Hα+[N II]), F775 (SDSS i)
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    Pencil Nebula, NGC 2736
  • Object Description
    Object DescriptionThe type of astronomical object.
    Nebula in the Vela Supernova Remnant
  • Release Date
    June 5, 2003
  • Science Release
    Supernova Shock Wave Paints Cosmic Portrait
  • Credits
    NASA, Hubble Heritage Project
