Compass and Scale Image for Binary Star System Stein 2051

Compass and Scale Image for Binary Star System Stein 2051
This Hubble Space Telescope image shows the binary star system Stein 2051 on October 1, 2013, consisting of the brighter, redder "A" component at lower right and the fainter, bluer "B" component near the center, a white dwarf star. Because these stars are relatively close to Earth, only 17 light-years away, they appear to move in the sky relative to the much more distant background stars in several months of observations with Hubble. The wavy blue line traces this motion, due to their true motion relative to the sun combined with the parallax due to the motion of Earth around the sun. Stein 2051 B appeared to pass close enough to one of these background stars, labeled "source" that the light from the source star was bent due to the mass of the white dwarf star. This color image was made by combining images taken in two filters with Hubble's Wide Field Camera 3 (WFC3/UVIS) instrument.

About the Object

  • R.A. Position
    R.A. PositionRight ascension – analogous to longitude – is one component of an object's position.
    04h 31m 13s
  • Dec. Position
    Dec. PositionDeclination – analogous to latitude – is one component of an object's position.
    +58º 58' 41"
  • Constellation
    ConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.
    Camelopardalis
  • Distance
    DistanceThe physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs.
    17 light-years, 5.5 parsecs

About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.
    The image was created from Hubble data from proposals 13457 and 13850 P.I. K. Sahu (STScI).
  • Instrument
    InstrumentThe science instrument used to produce the data.
    WFC3/UVIS
  • Exposure Dates
    Exposure DatesThe date(s) that the telescope made its observations and the total exposure time.
    Oct. 2013 - Oct. 2015
  • Filters
    FiltersThe camera filters that were used in the science observations.
    F606W (wide V), F814W (I)
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    Stein 2051 B, WD 0426+588
  • Object Description
    Object DescriptionThe type of astronomical object.
    White dwarf star
  • Release Date
    June 7, 2017
  • Science Release
    Hubble Astronomers Develop a New Use for a Century-Old Relativity Experiment to Measure a White Dwarf’s Mass
    Read the release
  • Credit
    NASA, ESA, and K. Sahu (STScI)

Downloads

  • 400 × 400
    png (199.06 KB)
  • Full Res, 1800 × 1200
    png (1.12 MB)
  • Full Res, 1800 × 1200
    tif (1.15 MB)
  • 2000 × 1333
    png (1.24 MB)
Compass and Scale Image for Binary Star System Stein 2051
Color Info
Color InfoA brief description of the methods used to convert telescope data into the color image being presented.

This image is a composite of separate exposures acquired by the WFC3/UVIS instrument on the Hubble Space Telescope. Two filters were used to sample different wavelength ranges. The color results from assigning different hues (colors) to each monochromatic (grayscale) image associated with an individual filter. In this case, the assigned colors are: cyan F606W and orange F814W.

Compass and Scale
Compass and ScaleAn astronomical image with a scale that shows how large an object is on the sky, a compass that shows how the object is oriented on the sky, and the filters with which the image was made.
