Compass and Scale Image of the GOODS/ERS2 Field

Compass and Scale Image of the GOODS/ERS2 Field

About the Object

  • R.A. Position
    R.A. PositionRight ascension – analogous to longitude – is one component of an object's position.
    03h 32m 40.23s
  • Dec. Position
    Dec. PositionDeclination – analogous to latitude – is one component of an object's position.
    -27° 43' 9.86"
  • Constellation
    ConstellationOne of 88 recognized regions of the celestial sphere in which the object appears.
    Fornax
  • Dimensions
    DimensionsThe physical size of the object or the apparent angle it subtends on the sky.
    This image is approximately 9.68 arcminutes wide by 4.27 arcminutes high.

About the Data

  • Data Description
    Data DescriptionProposal: A description of the observations, their scientific justification, and the links to the data available in the science archive.
    Science Team: The astronomers who planned the observations and analyzed the data. "PI" refers to the Principal Investigator.
    The image was created from Hubble WFC3 data from proposal 11359, R. O'Connell (University of Virginia) and collaborators, combined with the HST/ACS GOODS v2.0, which includes data from proposals 9425 and 9583, P.I. M. Giavalisco; 9727, P.I. Saul Perlmutter; 9728, 10339, and 10340, P.I. A. Riess.
  • Instrument
    InstrumentThe science instrument used to produce the data.
    HST>ACS/WFC, HST>WFC3/UVIS, and HST>WFC3/IR
  • Exposure Dates
    Exposure DatesThe date(s) that the telescope made its observations and the total exposure time.
    Sept. 2002 - Dec. 2004, Exposure Time: 96 orbits (ACS) and Sept. 6, 2009 - Oct. 11, 2009, Exposure Time: 104 orbits (WFC3)
  • Filters
    FiltersThe camera filters that were used in the science observations.
    WFC3/IR: F098M, F125W, and F160W ACS/WFC: F435W, F606W, F775W, and F850LP WFC3/UVIS: F225W, F275W, and F336W
  • Object Name
    Object NameA name or catalog number that astronomers use to identify an astronomical object.
    GOODS-S/ERS, GOODS South Field WFC3 Early Release Science Data (GOODS-S WFC3 ERS), Chandra Deep Field South (CDF-S)
  • Object Description
    Object DescriptionThe type of astronomical object.
    Cosmological Survey
  • Release Date
    January 5, 2010
  • Science Release
    Galaxy History Revealed in This Colorful Hubble View
    Read the release
  • Credit
    Science: NASA, ESA, R. Windhorst, S. Cohen, M. Mechtley, and M. Rutkowski (Arizona State University, Tempe), R. O'Connell (University of Virginia), P. McCarthy (Carnegie Observatories), N. Hathi (University of California, Riverside), R. Ryan (University of California, Davis), H. Yan (Ohio State University), and A. Koekemoer (Space Telescope Science Institute); Illustration: NASA, ESA, and Z. Levay (STScI)

Downloads

  • 1200 × 529
    jpg (273.84 KB)
  • 400 × 177
    jpg (28.85 KB)
  • PDF
    (1.22 MB)
  • 3600 × 1588
    jpg (1.54 MB)
  • 200 × 200
    jpg (16.09 KB)
  • 400 × 177
    jpg (28.85 KB)
  • 1200 × 529
    jpg (273.84 KB)
Compass and Scale Image of the GOODS/ERS2 Field
Color Info
Color InfoA brief description of the methods used to convert telescope data into the color image being presented.

The image is a composite of separate exposures made by the WFC3 and ACS instruments on the Hubble Space Telescope. In total, 10 filters were used to sample a very wide wavelength range. The color results from assigning different hues (colors) to combinations of the monochromatic images. In this case, the assigned colors are: Red: WFC3/IR F125W + F160W Green: ACS/WFC F606W + F775W + F850LP + WFC3/IR F098M Blue: WFC3/UVIS F225W + F275W + F336W + ACS/WFC F435W

Compass and Scale
Compass and ScaleAn astronomical image with a scale that shows how large an object is on the sky, a compass that shows how the object is oriented on the sky, and the filters with which the image was made.
